Operating Temperature Range
-5 to +40°C(+23 to +104°F)
Operating Humidity Range
5 to 90%RH (No Condensation)
Input Video Signal
0.5-1.0 Volts P-P
Input DDC Signal
5 volts p-p(TTL)
Support Video format
8Kx4K/4Kx2K/1080P/1080i/720P/576P/576i/480P/480i
Support Video Color Format
deep color 10bit(8K60hz YUV4:2:0)
Support Audio Format
LPCM, DTS, Dolby(CH7.1)
Data transfer speed rate
40Gbps (Maximum)
HDCP
Compliant HDCP2.2/1.4
Power consumption
1.65watts(Maximum)
Dimension (L×W×H)
104.4x86x28.3mm
Net Weight
155g
