114-436-4 16CH M-SERIES NVR WITH 4TB HD

{tab Overview}

114-436 16CH IP NVR WITH 4TB HD - HIKVISION

Hikvision DS-7616NI-M2/16P 16CH Ultra Series NVR inc 4TB HDD 256Mbps Bit Rate Input Max(up to 16-ch IP video),16x4MP decoding capability,HDMI up to 8K, 2 SATA Interfaces, 16 independent PoE network interfaces, alarm I/O: 4/1, 380 1U case

Features:

• H.265 /H.265/H.264 /H.264 video formats

• Up to 16ch IP camera inputs

• Up to 16ch@4MP decoding capacity

• Up to 256 Mbps incoming bandwidth

• Inc 4TB HDD

{tab specs}

Video And Audio

• IP Video Input: 16-ch Up to 32 MP resolution
  *: After ultra HD resolution mode is enabled, the NVR supports up to 8-ch 32 MP/24 MP IP video inputs.
• Incoming Bandwidth256 Mbps

• Outgoing Bandwidth256 Mbps

• HDMI Output8K (7680 × 4320)/30Hz, 4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz

• VGA Output1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz

• Video Output ModeHDMI/VGA independent output

• CVBS Output1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480

• Audio Output1-ch, RCA (Linear, 1 KΩ)

• Two-Way Audio1-ch, RCA (2.0 Vp-p, 1 KΩ, using the audio input)

Decoding

• Decoding FormatH.265 /H.265/H.264 /H.264

• Recording Resolution
  32 MP/24 MP/12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA /4CIF/DCIF/ 2CIF/CIF/QCIF

*: After ultra HD resolution mode is enabled, the NVR supports up to 8-ch 32 MP/24 MP IP video inputs.

• Synchronous Playback16-ch

• Decoding Capability2-ch@32 MP (30 fps)/2-ch@24 MP (30 fps)/4-ch@12 MP (20 fps)/8-ch@8 MP (25 fps)/16-ch@4 MP (30 fps)

• Dual-Stream RecordingSupport

• Stream TypeVideo, Video & Audio

• Audio CompressionG.711ulaw/G.711alaw/G.722/G.726/AAC/MP2L2

Network

• Remote Connection128

• Network ProtocolTCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS

• Network Interface1, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface

PoE

• Interface16, RJ-45 10/100 Mbps self-adaptive Ethernet interface

• Power≤ 200 W

• Standard IEEE 802.3 af/at

Auxiliary Interface

• SATA2 SATA interfaces

• CapacityUp to 14 TB capacity for each HDD

• Alarm In/Out4/1

• USB InterfaceFront panel: 1 × USB 2.0; Rear panel: 1 × USB 3.0

General

• Power Supply100 to 240 VAC, 50 to 60 Hz

• Consumption≤ 15 W (without HDD and PoE off)

• Working Temperature-10 °C to 55 °C (14 °F to 131 °F)

• Working Humidity10% to 90%

• Dimension (W × D × H)385 × 315× 52 mm (15.2" × 12.4" × 2.0")

• ≤ 3 kg (without HDD, 2.2 lb.)

Certification

• FCCPart 15 Subpart B, ANSI C63.4-2014
  CE

• EN 55032:2015 A1:2020, ENIEC61000-3-2:2019 A1:2021, EN 61000-3-3:2013 A1:201 9, EN 50130-4:2011 A1:2014, EN 55035:2017 A11:2020
