| Video and Audio | IP Video Input | 4ch up to 32MP resolution |
| Incoming Bandwidth | 40 Mbps |
| Outgoing Bandwidth | 80 Mbps |
| HDMI Output | - 8K (7680 × 4320)/30Hz
- 4K (3840 × 2160)/30Hz
- 2K (2560 × 1440)/60Hz
- 1920 × 1080/60Hz
|
| VGA Output | 1920 × 1080/60Hz |
| Video Output Mode | HDMI/VGA independent output |
| CVBS Output | N/A |
| Audio Output | 1-ch, RCA (Linear, 1K Ω) |
| Two-Way Audio | 1-ch, RCA (2.0V p-p, 1K Ω, using the audio input) |
| Decoding | Dual-Stream Recording Support | Yes |
| Decoding Format | H.265+ / H.265 / H.264+ / H.264 |
| Decoding Capability | - 4-ch @ 8 MP (30 fps)
- 8-ch @ 4 MP (30 fps)
- 16-ch @ 1080p (30 fps)
|
| Synchronous Playback | 4-ch |
| Recording Resolution | 32MP / 24MP / 12MP / 8MP / 6MP / 5MP / 4MP / 3MP / 1080p / UXGA / 720p / VGA / 4CIF / DCIF / 2CIF / CIF / QCIF |
| Stream Type | Video, Video & Audio |
| Audio Compression | G.711ulaw / G.711alaw / G.722 / G.726 / AAC / MP2L2 |
| Network | Remote Connection | 128 |
| Network Protocol | TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS |
| Network Interface | 1 × RJ-45 10/100/1000Mbps self-adaptive Ethernet interface |
| PoE | Interface | 4 × RJ-45 10/100Mbps self-adaptive Ethernet interface |
| Power | ≤60W |
| Standard | IEEE 802.3 af/at |
| Auxiliary Interface | SATA | 1 × SATA interfaces |
| Capacity | Up to 16TB capacity for each HDD |
| Alarm In/Out | 4/1 |
| USB Interface | - Front Panel: 1 × USB 2.0
- Rear Panel: 1 × USB 2.0
|
| Power Supply | 48V DC, 1.875A |
| Consumption | ≤15W (without HDD and PoE off) |
| Packaging | Working Temperature | −10°C to 50°C (14°F to 122°F) |
|---|
| Working Humidity | 10% to 90% |
| Dimensions (W×D×H) | 320mm × 240mm × 48mm (12.4″ × 9.4″ × 1.9″) |
| Weight | ≤1.2kg (without HDD, 2.6lb.) |
| Certifications | CE EN 55032:2015+A1:2020, ENIEC61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:201 9, EN 50130-4:2011+A1:2014, EN 55035:2017+A11:2020 |
