| Image Sensor | 1/2.7” Progressive Scan CMOS |
|---|
| Shutter Speed | 1/3 to 1/10000 s |
|---|
| Slow Shutter | Yes |
|---|
| Aperture | F1.6 |
|---|
| Lens | 2.8 mm, Fixed Focal Lens |
|---|
| Lens Mount | M12*P 0.5 |
|---|
| FOV | Horizontal FOV: 100°, Vertical FOV: 54°, Diagonal FOV: 118° |
|---|
| Minimum Illumination | 0.005 Lux; 0 Lux with IR/White Light |
|---|
| Day/Night Mechanism | IR Cut Filter |
|---|
| Day/Night Switch | Unified/ Scheduled/ Auto |
|---|
| White LED | • Quantity: 4
• Range: 98 ft (30m) |
|---|
| IR LED | • Quantity: 4
• Range: 98 ft (30 m)
• Wavelength: 850nm |
|---|
| Illuminator On/Off Control | Auto/Scheduled/Always on/Always off |
|---|
| Max. Resolution | 2688 x 1520 |
|---|
| Main Stream | • Frame Rate:
50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps
• Resolution:
2688x1520, 2560x1440, 2304x1296, 2048x1280, 1920x1080, 1280x720
• Note:
If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps. |
|---|
| Sub-Stream | • Frame Rate:
50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps
• Resolution:
704x576,640x480, 352x288, 320x240
• Note:
If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps. |
|---|
| Video Compression | • Main Stream: H.265+/H.265/H.264+/H.264
• Sub-Stream: H.265/H.264 |
|---|
| Operating Temperature | -30 °C to 60 °C (-22 °F to 140 °F) |
|---|
| Operating Humidity | 95% or Less (Non-Condensing) |
|---|
| Power Supply | • 12V DC ± 5%, Max. 11 W, 5.5 mm Coaxial Power Plug
• PoE: 802.3af/at, class 0, Max. 12 W |
|---|
| Weatherproof Rating | IP67 |
|---|
