NVR2016H-16P 16 CHANNEL POE+ NETWORK VIDEO RECORDER

VIGI

Code: 43171324

1.02 kg
4895252504040
EACH
10
Low Stock
$399 inc GST
Increase value Decrease value
Qty Each (inc GST) Each
Request Price Match
Enter 4 digit postcode

VIGI 16 Channel PoE Network Video Recorder

  • 16-Channel Live View and 4K HDMI Video Output
  • 16× 10/100 Mbps PoE Ports with 90 W PoE Budget?
  • Up to 8-ch @ 2MP (25fps) / 4-ch @ 4MP (25fps) Decoding Capability
  • 16-Channel Synchronous Playback
  • 80 Mbps Incoming Bandwidth and 60 Mbps Outgoing Bandwidth
  • 2× SATA Interfaces and 1 Up to 16 TB*
  • H.265 Compression Technology
  • HDMI and VGA Simultaneous Output
  • Remote Monitoring
Video and Audio
IP Video Input 16-Channel
Incoming Bandwidth 80 Mbps
Outgoing Bandwidth 60 Mbps
HDMI Output Resolution 1 Channel, Resolution: 3840x2160/30Hz, 1920x1080/60Hz, 1680x1050/60Hz, 1440x900/60Hz, 1280x1024/60Hz, 1280x720/60Hz
VGA Output Resolution 1 Channel, Resolution: 1920x1080/60Hz, 1680x1050/60Hz, 1440x900/60Hz, 1280x1024/60Hz, 1280x720/60Hz
Video Output Mode HDMI/VGA Simultaneous Output
Multi-View Display 1/4/6/8/9/16
DECODING
Audio Compression G.711A/G.711U/G.726
Video Compression H.265 /H.265/ H.264 /H.264
Record Resolution 8MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/
2CIF/CIF/QCIF
Synchronous Playback 16-Channel
Capability 25fps:
2-ch @ 8MP, 4-ch @ 4MP, 8-ch @ 2MP

30fps:
4-ch @ 3MP, 2-ch @ 5MP
Record Management
Record Mode Manual Recording, Scheduling Recording, Motion Detection Recording
Playback Mode Instant Playback, Regular Playback, Tag Playback, Event Playback
Backup Mode Regular Backup, Video Clip Backup
Playback Function Play, Pause, Stop, Fast Forward, Fast Backward, Play By Frame, Full
Screen, Video Clip, Export Clip, Digital Zoom, Lock Recording, Audio On/Off
NETWORK
Protocol UPnP (Plug and Play), NTP (Network Timing)
Mobile Phone Access Android, iOS
Web Browser Chrome (57 ), Firefox (52 ), Edge (91 )
Interoperability ONVIF, CGI
External Interface
Network Interface 1, RJ-45 10/100/1000 Mbps Self-Adaptive Ethernet Interface
USB Interface 1 Front USB 2.0 Port, 1 Rear USB 2.0 Port
Audio Interface 1, Audio In; 1, Audio Out
Alarm In/Out N/A
Serial Interface N/A
Power 1× DC Jack
Reset Button 1
Speaker N/A
eSATA 1
HDMI 1
VGA 1
HARD DISK
SATA 2 SATA Interfaces
Capacity Up to 16 TB Capacity for Each HDD*
PoE
Standard 802.3at/af Compliant
Interface 1- 8, RJ-45 10/100 Mbps Self-Adaptive Ethernet Interface
PoE Budget 90 W Available for All PoE Ports, 30 W Max per Port
Alarm
General Alarm Motion Detection, Video Tampering, Line-Crossing Detection, Intrusion Detection, Region Entering Detection, Region Exiting Detection, Object Abandoned/Removal Detection, Vehicle Detection, Human Detection, Smart Frame
Anomaly Alarm Video Loss, Offline and IP Conflict, Disk Exception, Login Exception, Fan Exception
Alarm Linkage Recording, White Light Alarm, Buzzer, Log, Audible Alarm
GENERAL
Storage Temperature -40–70 °C
Storage Humidity 10%~90% RH Non-Condensing
Package Contents VIGI Network Video Recorder
Power Adapter
Power Cables
HDD Power Cables
HDD Data Cables
Mounting Accessories
Mouse
Quick Installation Guide
Working Temperature NVR: -10–55 °C
Power Adapter: 0–40 °C
Working Humidity 10%~90% RH Non-Condensing
Dimensions( W X D X H ) 330 × 285 × 45 mm
Net Weight 1.9 Kg
Gross Weight 3.2 Kg
Power Supply 53.5V DC/2.43A
Power Consumption 6.2 W (Without Disk)
40 W (With Disk)
Certifications CE, EAC, UKCA, RCM, Triman, BSMI, VCCI, FCC, IC, HDMI
