CAMERA
Sensor
1/2.9"SONY2.43MpixelsCMOS
Effectivepixels
1920*1080
HDAHDoutput
1080P
Resolution
1280H(CVBSinput)
Min.Illumination
0Lux(IRON)
SyncSystem
Internal
Lens
2.8-12 mmlens
ElectronicShutter
Auto/Manual(X30~1/50000)/FLK
S/NRate
≥50db(AGCOFF)
Videooutput
1.0Vp-pcompositevideooutput,75O
outputmodel
PAL/ NTSCadjustable
OSDmenu
Whitebalance
ATW/ AWC-SET/ INDOOR/ OUTDOOR/ MANUAL/ AWB
NR
2DNR/ 3DNR,OFF
Imageadjustable
Brightness,sharpness,AGC
DWDR
AUTO/ ON/OFF
BLC
BLC/HsbLC/OFF
AGC
ON/OFF/AUTO (1-15)
Privacymask
OFF/ON(4zone)
Motiondetection
Mirror
horizontal/vertical/HVmirror
Sens-up
OFF/ON (X30, X25, X20, X15, X10, X8, X6, X4, X2)
Lensshadingcompensation
OFF/ ON
DPC
Auto/Manual
Defog
OFF/Auto(EffectiveunderB/ Wmodel)
Chinese,Englishetc12languages
Dual-output
HDAHD/analogCVBSoptional
General
Transmissiondistance
75 - 3/ 300m, 75 - 5/ 500m
IRdistance
powersupply
DC12V ±10%
Power(max)
280mA ± 10mA (IRON)
OperatingTemperature
−20°C~55°C/0%-90%
Dimensions(mm)
66(W)*66(H)*166(L)mm
Weight/ PC(g)
400g
Expecting AHD but only getting Composite?Our AHD cameras come out of the box configured to output Composite (CVBS) to allow installers with test monitors to quickly align the camera. Once positioned correctly, you can set the camera to AHD output using the setting shortcuts below:
