1: Maximum wireless signal rates are the physical rates derived from IEEE Standard 802.11 specifications. Actual wireless data throughput, wireless coverage, and connected devices are not guaranteed and will vary as a result of network conditions, client limitations, and environmental factors, including building materials, obstacles, volume and density of traffic, and client location.
2: 2.5 Gbps internet speeds require compatible service plans and equipment. Actual network speed may be limited by the rate of the product's Ethernet WAN or LAN port, the rate supported by the network cable, Internet service provider factors and other environmental conditions.
3: TP-Link EasyMesh-compatible products can network with other devices that use EasyMesh. Failed connections may be due to firmware conflicts of different vendors. The EasyMesh-compatible function is still being developed on some models and will be supported in subsequent software updates.
4: HomeShield includes the Free Basic Plan. Fees apply for the Pro Plan. Visit tp-link.com/homeshield for more information.
5: Wi-Fi generations represent the wireless standard IEEE 802.11 a/b/g/n/ac/be. All devices need to support 802.11 Wi-Fi protocols.
| WIRELESS | Wi-Fi Speeds | BE3600 - 5 GHz: 2882 Mbps (802.11be)
- 2.4 GHz: 688 Mbps (802.11be)
|
|---|
| Wi-Fi Range | 3 Bedroom Houses- 4 × External Antennas: Multiple antennas form a signal-boosting array to cover more directions and large areas.
- Beamforming: Concentrates wireless signal strength towards clients to expand Wi-Fi range.
|
| Wi-Fi Capacity | High- Dual-Band: Allocate devices to different bands for optimal performance.
- 2 × 2 MU-MIMO: Simultaneously communicates with multiple MU-MIMO clients.
- OFDMA: Simultaneously communicates with multiple clients.
- Airtime Fairness: Improves network efficiency by limiting excessive occupation.
- DFS: Access an extra band to reduce congestion.
- 4 Streams: Connect your devices to more bandwidth.
|
| Advanced Features | - Multi-Link Operation (MLO)
- 4K-QAM
- Multi-RUs
- EasyMesh-Compatible
- Works with Alexa and Google Assistant
- IoT Network
|
| Wireless Mode | - Router Mode
- Access Point Mode
|
| SECURITY | Network Security | - SPI Firewall
- Access Control
- IP & MAC Binding
- Application Layer Gateway
|
|---|
| HomeShield Security | - Real-Time IoT Protection
- Malicious Site Blocker
- Intrusion Prevention System
- DDoS Attack Prevention
- Home Network Scanner
|
| Guest Network | - 1 × 5 GHz Guest Network
- 1 × 2.4 GHz Guest Network
|
| VPN Server | - OpenVPN Server
- PPTP VPN Server
- L2TP VPN Server
- WireGuard VPN Server
|
| VPN Client | - Open VPN Client
- PPTP VPN Client
- L2TP VPN Client
- WireGuard VPN Client
|
| Wi-Fi Encryption | - WPA
- WPA2
- WPA3
- WPA/WPA2-Enterprise (802.1x)
|
| HARDWARE | Ethernet Ports | - 1 × 2.5 Gbps WAN
- 1 × 2.5 Gbps LAN
- 3 × 1 Gbps LAN
|
|---|
| USB Support | 1 × USB 3.0
Supported Partition Formats:Supported Functions:- FTP Server
- Media Server
- Samba Server
|
| Buttons | - Power On/Off Button
- Wi-Fi On/Off Button
- LED Button
- WPS Button
- Reset Button
|
| Power | - 12V, 2A (US)
- 12V, 1.5A (EU)
|
| SOFTWARE | Protocol | |
|---|
| Service Kit | HomeShield
Learn More> |
| EasyMesh | Compatible with EasyMesh |
| Parental Controls | HomeShield Parental Controls- Custom Profiles
- Professional Content Filter Library
- Family Time
- Bedtime
- Off Time
- Time Rewards
- Family Online Time Ranking
- Pause the Internet
- Weekly and Monthly Reports
|
| WAN Type | - Dynamic IP
- Static IP
- PPPoE
- PPTP
- L2TP
|
| Quality of Service | QoS by Device |
| Cloud Service | - Auto Firmware Upgrade
- TP-Link ID
- DDNS
|
| NAT Forwarding | - Port Forwarding
- Port Triggering
- DMZ
- UPnP
|
| IPTV | - IGMP Proxy
- IGMP Snooping
- Bridge
- Tag VLAN
|
| DHCP | - Address Reservation
- DHCP Client List
- Server
|
| DDNS | |
| Management Features | |
| ENVIRONMENT | Operating Temperature | 0°C~40°C (32°F~104°F) |
|---|
| Operating Humidity | 10%~90% non-condensing |
| GENERAL | System Requirements | - Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser
- Cable or DSL Modem (if needed)
- Subscription with an internet service provider (for internet access)
|
|---|
| Certifications | CE, FCC, RoHS |
