| HARDWARE FEATURES | Processor | Qualcomm 750MHz CPU, MIPS 74Kc |
|---|
| Memory | 128MB DDR2 RAM, 16MB Flash |
| Interface | - 1 × 10/100/1000 Mbps Shielded Ethernet Port (LAN/POE)
- 1 × Reset Button
|
| Power Supply | - Passive Power over Ethernet via LAN (+4, 5 pins; −7, 8 pins)
- Voltage range: 16-27V DC
|
| Dimensions (W×D×H) | 366mm × 280mm × 207mm (14.4″ × 11.0″ × 8.1″) |
| Antenna Gain | 23 dBi |
| Antenna Beamwidth | 9° (Azimuth) / 7° (Elevation) |
| Protection | - 15 KV ESD Protection
- 6 KV Lightning Protection
|
| Enclosure | - Material: Outdoor PC stabilized plastic
- Weatherproof: IP65 water and dust proof design
|
| WIRELESS FEATURES | Wireless Standards | IEEE 802.11a/n/ac |
|---|
| Wireless Speeds | - Up to 867 Mbps (80 MHz, Dynamic)
- Up to 400 Mbps (40 MHz, Dynamic)
- Up to 173.4 Mbps (20 MHz, Dynamic)
|
| Frequency | 5.15 – 5.85 GHz |
| Transmit Power | Max. 27 dBm (Adjustable power by 1dBm) |
| SOFTWARE FEATURES | Network Configuration | - WAN: Static/ Dynamic/ PPPoE
- LAN: Static/ Dynamic/ DHCP
- Forwarding: ALG/ UPnP/ Virtual Server/ Port Trigger
- Security: SPI Firewall/ Ping Forbidden/ DoS Protection
- Access Control
- Static Routing
- Bandwidth Control
- IP & MAC Binding
|
|---|
| Wireless Configurations | - Selectable Channel Width: 20/40/80MHz
- Auto Channel Selection
- Transmit Power Control
- Dynamic Frequency Selection (DFS)
- WDS Enable/ Disable
- Security: WPA/WPA2, WPA-PSK/WPA2-PSK (AES/TKIP) Encryption
- SSID Broadcast Enable/ Disable
- Multi-SSID with VLAN Tagging (AP Mode only)
- Distance / ACK Timeout Setting
- Wireless MAC Address Filter
- Wireless Advanced: Beacon Interval / RTS Threshold / Fragmentation Threshold / DTIM Interval / AP Isolation / Short GI / Wi-Fi Multimedia Long Range PtP
|
| Management | - Discovery and Remote Management via Pharos Control application
- HTTP/ HTTPS Web-based management
- System log
- SNMP Agent(v2c)
- Ping Watch Dog
- Dynamic DDNS
- SSH Server
|
| System Tools | - Indicators: Signal Strength / Noise / Transmit CCQ / CPU / Memory
- Monitors: Throughput / Stations / Interfaces / ARP / Routes / WAN / DHCP
- Spectrum Analyser
- Speed Test
- Ping
- Traceroute
- Antenna Alignment
|
| System-level Optimisations | Optimised IGMP Snooping / Proxy for multicast applications |
| POE ADAPTER FEATURES | Dimensions (W×D×H) | 85.8mm × 43.9mm × 29.7mm |
|---|
| Interfaces | - 1 × AC Jack with Earth Ground
- 1 × 10/100/1000 Mbps Shielded Ethernet Port (Power + Data)
- 1 × 10/100/1000 Mbps Shielded Ethernet Port (Data)
|
| Button | Remote Reset Button |
| Power Status LEDs | Green |
| Input | 100-240V AC, 50/60Hz |
| Output | 24V DC, 0.6A Max
+4, 5 pins; −7, 8 pins. (Support up to 60m Power over Ethernet) |
| Efficiency | >84.29% |
| Certifications | CE/FCC/UL/IC/GS/PSB/C-tick/SAA/S-Mark/KC-mark |
| ENVIRONMENT | Operating Temperature | −40°C ~ 70°C (−40°F ~ 158°F) |
|---|
| Storage Temperature | −40°C ~ 70°C (−40°F ~ 158°F) |
| Operating Humidity | 10%~90% non-condensing |
| Storage Humidity | 5%~95% non-condensing |
| OTHERS | Certification | CE, FCC, RoHS, IP65, IC |
|---|
| Package Contents | - Outdoor Wireless CPE
- 24V 0.5A Passive PoE Adapter
- Pole Mounting Kits
- AC Power Cord
- Installation Guide
|
| System Requirements | Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 10, Windows 8, Windows 7, MAC OS, NetWare, UNIX or Linux
Note: We recommend you to use one of following Web browsers for an improved user experience: Google Chrome, Safari, and Firefox. IE browsers are not recommended. |
