| Function | PE6108A | PE6108B | PE6108G |
| Electrical |
| Nominal Input Voltage | 100 – 120 VAC | 100 – 240 VAC | 100 – 240 VAC |
| Maximum Input Current | 15A Max; 12A(UL de-rated) | 15A Max; 12A(UL de-rated) | 10A Max |
| Input Frequency | 50-60 Hz | 50-60 Hz | 50-60 Hz |
| Input Connection | NEMA 5-15P | NEMA 6-15P | IEC 60320 C14 |
| Input Power | 1800 VA(Max); 1440 VA(UL de-rated) | 3120 VA(Max); 2496 VA(UL de-rated) | 2300 VA(Max) |
| Outlet Type | Total: 8 x NEMA 5-15R | Total: 8 x IEC320 C13 | Total: 8 x IEC320 C13 |
| Nominal Output Voltage | 100 – 120 VAC | 100 – 240 VAC | 100 – 240 VAC |
| Maximum Output Current (Outlet) | NEMA 5-15R: 15A(Max); 12A(UL de-rated) | C13: 15A(Max); 12A(UL de-rated) | C13: 10A(Max) |
| Maximum Output Current (Bank) | 15A(Max); 12A(UL de-rated) | 15A(Max); 12A(UL de-rated) | 10A(Max) |
| Maximum Output Current (Total) | 15A(Max); 12A(UL de-rated) | 15A(Max); 12A(UL de-rated) | 10A(Max) |
| Breakers | 1 x 15A Non-Fuse Breaker | 1 x 15A Non-Fuse Breaker | 1 x 15A Non-Fuse Breaker |
| Metering | Bank level Current, Voltage, VA , PF and KWh Monitoring | Bank level Current, Voltage, VA , PF and KWh Monitoring | Bank level Current, Voltage, VA , PF and KWh Monitoring |
| Outlet Switching | Yes | Yes | Yes |
| Environment Sensor Ports | 2 | 2 | 2 |
| Metering Accuracy | Voltage Range: 100VAC ~ 250VAC /-1%
Power Range: 100W ~ Maximum Capacity /- 2%
Current Range: 0.1A~1A /- 0.1A, 1A~20A /-1% | Voltage Range: 100VAC ~ 250VAC /-1%
Power Range: 100W ~ Maximum Capacity /- 2%
Current Range: 0.1A~1A /- 0.1A, 1A~20A /-1% | Voltage Range: 100VAC ~ 250VAC /-1%
Power Range: 100W ~ Maximum Capacity /- 2%
Current Range: 0.1A~1A /- 0.1A, 1A~20A /-1% |
| Physical Properties |
| Dimensions (L x W x H) | 43.24 x 22.04 x 4.40 cm
(17.02 x 8.68 x 1.73 in.) | 43.24 x 22.04 x 4.40 cm
(17.02 x 8.68 x 1.73 in.) | 43.24 x 22.04 x 4.40 cm
(17.02 x 8.68 x 1.73 in.) |
| Weight | 2.77 kg ( 6.1 lb ) | 2.77 kg ( 6.1 lb ) | 2.77 kg ( 6.1 lb ) |
| Power Cord Length | 3 m | 3 m | 3 m |
| Environmental |
| Temperature (Operating / Storage) | 0 – 50°C / -20 – 60°C | 0 – 50°C / -20 – 60°C | 0 – 50°C / -20 – 60°C |
| Humidity (Operating & Storage) | 0 – 80% RH, Non-Condensing | 0 – 80% RH, Non-Condensing | 0 – 80% RH, Non-Condensing |
| Compliance |
| EMC Verification | FCC, Others by Request | FCC, Others by Request | CE, Others by Request |
| Safety Verification | TUV-CB, cTUVus, Others by Request | TUV-CB, cTUVus, Others by Request | TUV-CB, CE-LVD, Others by Request |
| Note | For some of rack mount products, please note that the standard physical dimensions of WxDxH are expressed using a LxWxH format. |
