MQS37 2CH LINE LEVEL MIXER

MQS37 MIXER

Specifications:

• CH1 : 1/4" unbalanced jack for receiving line or instrument level signals.
• CH2 : Stereo RCA input for receiving line level signals.
• CH1 max. gain: 32dB
• CH2 max. gain: 20dB
• CH1 input impedance: 10K Ohms
• CH2 input impedance: 20K Ohms
• Output impedance: 50 Ohms
• Power: 12V DC /150mA adapter (Supplied)
• Dimension: 95 x 73 x 40mm
• Weight: 229g

Feature:

• Use for mixing vocals and/or instrumentals from one mixer with recorded music, then send it all to one channel on a PA, broadcast or recording mixer
• Each channel has a volume control
• The MQS-37 is a two-channel mixer for mixing a 1/4" line signal such as a wireless microphone, and a stereo RCA signal such as a CD player.
