AMP8125 8 CHANNEL HI / LOW Z DSP MATRIX AMPLIFIER

RTI AMP8125 - 8ch DSP Matrix amplifier- 8x 125w at 8 ohm - 4x 250w at 70/100v

The AMP-8-125 power amplifier delivers configurable and reliable high performance audio power amplification for commercial and hospitality applications that demand a mix of low impedance and high impedance outputs. With a compact 1U design, this DSP-enabled Class-D amplifier can drive low impedance 4Ω to 16Ω loudspeakers as well as high impedance 70V/100V transformer-coupled loudspeakers. The AMP-8-125 can accept eight balanced or unbalanced analog inputs and one stereo S/PDIF digital input and delivers either four low impedance stereo outputs at 125W per channel, or four 70V/100V mono outputs at 250W per channel.

For set-up, the RTI web GUI enables effortless browser-based configuration of the installed system. Its DSP configuration options include multizone setup, input mixing, priority and ducking, restriction, input and output EQ, S/PDIF output routing, high-pass filter, speaker presets, delay, Wall-S1 controller configuration, sine wave generator, and more.

Key Features

• Eight analog audio source input channels (balanced or unbalanced) and one digital input (S/PDIF).
• Four Lo-Z stereo or eight Lo-Z mono output zones, four Hi-Z mono output zones, or a mix of both.
• Class D amplifier provides a robust and clear audio experience with 125 Watts @ 4Ω/ 8Ω per channel or 250W @ 70V/100V per channel.
• Daisy-chain multiple amplifiers and expand the number of zones by distributing up to two audio inputs or zones.
• Built-in DSP allows for fine-tuning acoustic characteristics for each zone.
• Easy configuration via LAN or Wi-Fi.
• IP and GPIO control options.
• Free-standing installation or rack-mount (rack-mount kit included).

Other Details

• 4 Sources / 8 Channels
  • Four analog audio source inputs (balanced or unbalanced), 1 digital input.
• 4 Zones
  • Choose between standard stereo zones or a 70V/100V sound system.
• Full Matrix
  • Distribute four audio source inputs to four zones, expandable to more zones by daisy-chaining multiple AMP-8-125 units.
• Powerful Stereo Output
  • 125W power output per channel for stereo zones.
• Powerful 70V/100V Output
  • 250W per channel for 70/100V zones.
• Built-In DSP
  • Configure and optimize DSP and matrix settings with the in3tuitive web user interface.
• Ultra-Efficient
  • Cool Power® Class D amplifier technology ensures efficient heat dissipation and low power consumption.
• Audio Source Versatility
  • Use either analog or digital audio sources or a combination of both.
• Control
  • Control the unit with an RTI or 3rd party control systems via IP or use the GPIO control for controller for volume, standby, mute or trigger functions
• Mounting Options
  • Rack mount or free-standing installation with included rack ears and adhesive rubber feet.

Specifications:

In the box:

• AMP-8-125, power cord
• 6-pin Phoenix input connectors (4)
• 4-pin Phoenix output connectors (4)
• 8-pin Phoenix GPIO socket connector (1)
• adhesive rubber feet (4)
