Characteristic Impedance
50Ω
Frequency Range
0~4GHz
Operating Temperature
-55°C~ 155°C
Operating voltage
500V
Withstand voltage
1500V
Inner Conductor Resistance
≤1.5mΩ
Outer Conductor Resistance
insulation Resistance
≥5000MΩ
Vertical standing wave ratio
≤1.22/3GHz
Bending standing wave ratio
≤1.30/3GHz
Mechanical Endurance
500 times
1. Solder the pin to LMR400
2. Push the LMR400 into the plug
3. Crimp
