Name: IP50HDTX CONTRACTOR SERIES HD VIDEO TX OVER 1GB NETWORK VIDEO SCALER-BI-DIRECTIONAL IR- RS-232 & USB/KVM,
Brand: BLUSTREAM
SKU: 07350950
Price: 659 AUD
Availability: InStock

VIDEO SCALER-BI-DIRECTIONAL IR- RS-232 & USB/KVM,

Code: 07350950

EACH

Special
Buy-In

TRADE ALERT!

$659 inc GST

Increase value Decrease value

Qty	Each (inc GST)	Each

Request Price Match

Interested in purchasing this product?
This product is a special buy-in. Special buy-in products are goods especially bought in on customer's request. After acceptance, special buy-in products cannot be cancelled or the goods returned, unless Radio Parts and its supplier agrees to the cancellation of the corresponding order and return of goods. Prices are subject to change and in the event that our purchase price has changed, we will notify you before finalising your order. Please call us on (03) 93218300 for availability, ETA, or if you have further questions.

Click here if you agree to these terms and to show the Add To Cart button.

View Product

Freight Estimator Enter 4 digit postcode

{tab Overview}

Blustream IP50HD-TX Contractor Series HD Video Transmitter over 100Mbps Network

High Definition Video over IP Transmitter. Our Contractor HD Multicast distribution platform allows distribution of AV and control signals over a 100Mbps network.

The IP50HD-TX is an industry leading 1080p HDMI transmitter that, using H.265 compression technology, delivers HDMI, Bi-directional IR, RS-232 & USB/KVM up to lengths of 100m over standard network architecture.

The transmitter includes a HDMI loop-out for cascading to multiple devices and can be powered via PoE from the network switch or locally should the switch not support PoE. With multiple configuration options available the Multicast HD solution is ideal for both commercial and residential installations.

Key Features

Advanced HD video, control and KVM over network infrastructure
Extends HDMI up to a distance of 100m over a single CAT cable
Supports unicast transmission over unmanaged networks
Supports multicast transmission for large managed networks
Supports up to 1080p @ 60Hz
Features 1 × HDMI loop-out for integrating local displays or cascading to multiple devices
Supports PCM 2.0 channel audio only
Advanced signal management for independent routing of IR, RS-232, USB/KVM, and video/audio
PoE (Power over Ethernet) to power product from a PoE switch
HDCP1.4 compliant with advanced EDID management
Analogue L/R audio embedding and audio breakout (2ch PCM only)
Local 12V 1A power supply should Ethernet switch not support PoE (supplied separately)
Features 2 operational modes:

Matrix distribution (requires 100Mbps network switch)
One-to-one HDMI extender (no network switch required)

{tab Specifications}

Specifications

Video Input	1 × HDMI Type A, 19-pin, female, locking
Video Output	1 × LAN RJ45 connector, 1 × HDMI Type A, 19-pin, female, locking
Latency	3 frames (<120ms subject to video compression, frame rate and scaling) No latency on HDMI Loop out
Audio Input	1 × 3-pin Phoenix connector
Audio Output	1 × 3-pin Phoenix connector
Ethernet Port	1 × LAN RJ45 connector
RS-232 Serial Port	1 × 3-pin Phoenix connector
USB/KVM Host Port	1 × USB-Type B
IR Input	1 × 3.5mm stereo jack
IR Output	1 × 3.5mm mono jack
PoE Draw	3.7W (typical), 4.0W (max load)
Mounting Kit	Included
Dimensions (W×D×H)	190mm × 95mm × 25mm
Dimensions Including Connections (W×D×H)	190mm × 100mm × 25mm, without feet
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	−20°C to 60°C (−4°F to 140°F)

Box Contents

1 × IP50HD-TX
1 × IR Receiver
1 × IR Emitter
1 × Mounting Kit
4 × Rubber Feet

{/tabs}
